Connecting an AI phone agent to Yeastar
Yeastar builds phone systems for small and medium-sized businesses, such as the P-Series and the older S-Series. Both support SIP trunks, which is how Tibinet's AI agent joins them. Your IVR or queue sends callers to the agent, and the agent transfers them back to your team.
Yeastar and the AI agent
The P-Series comes as an appliance, as software and in the cloud. The S-Series is the older range. On both you connect external SIP services with a trunk. Your handsets, numbers and menus stay as they are.
How the integration works
- Register trunk with a username and password to the SIP address we give you. This also works behind NAT.
- Peer trunk if your Yeastar has a fixed public IP address. We then recognise your system by that address.
- Outbound route for the agent numbers and an inbound route for the transfer numbers you agree with us.
- Trunk type
- Register or peer
- Port
- 5060 (UDP and TCP), 5061 (TLS)
- Media (RTP)
- UDP 10000 to 20000
- Codecs
- G.711 A-law (preferred) and µ-law; G.722 on request
- DTMF
- RFC 4733 (RFC 2833)
Every setting on our side is listed on the technical details page.
What your administrator does
Add a trunk
Add a register or peer trunk using the details we send you.
Create an outbound route
Route the numbers 85XX and 88XXXXX to this trunk. Every agent has a fixed number starting with 88 and, on request, a short number such as 8500.
Create an inbound route
Add an inbound route for the transfer numbers, pointing to the right extension, ring group or queue.
Set codecs and DTMF
Choose G.711 A-law and set DTMF to RFC 2833/4733.
Make the agent a destination
Point an IVR option, a queue overflow or your out-of-hours rule to the agent's short number.
Test
We check the connection, you call the agent's short number, and on request we call a transfer number with a test message.
Transferring to your team
- Cold: our platform calls your Yeastar with a second call.
- REFER (optional): we ask your Yeastar to complete the transfer itself. If that fails, we fall back to the second call automatically.
- Warm: your colleague first hears a short summary, then presses 1 to take the call or 2 to decline it.
If nobody answers or the line is busy, the caller stays with the agent. The agent only calls numbers you have agreed with us in advance, and no call ever goes out to the public phone network over the trunk.
Points to watch
Related pages: connecting the AI agent to 3CX and to Grandstream UCM. All platforms are listed in the integrations overview.
Want to connect your Yeastar to the AI agent?
Leave your details. We will call you back and send you the trunk details.
Yeastar is a trademark of Xiamen Yeastar Digital Technology. Tibinet is not a partner of, or affiliated with, Yeastar.
Frequently asked questions
Yes, if you can add your own SIP trunk there. Otherwise, forward calls to a phone number of the agent.
Yes, through an option pointing to the agent's short number.
Yes, as long as the number is on the list of agreed destinations.
No. With a register trunk it also works behind NAT.
Yes. The S-Series supports SIP trunks, and the connection works the same way.
